JL Audio Transmitter & Receiver Kit JLINK TRX Wireless in Black - 96102

Product Details
JL Audio 96102 Transmitter & Receiver Kit JLINK TRX Wireless in Black
Using state-of-the-art wireless technology, the JLINK TRX system delivers pure, high-fidelity sound throughout your home, invisibly and effortlessly.
By broadcasting at an ultra-high frequency of 2.4 GHz, the JLINK TRX lets you connect any two line-level audio devices together, without the use of RCA signal cables to connect in between. Now you can send crystal clear, stereo sound from a source unit to a receiver, preamp or powered loudspeakers, wirelessly, up to 100 feet away (30 meters) without needing to route or hide long expanses of signal cables. RCA-type input/output connectors are compatible with most audio equipment and a compact design makes it easy to hide the transmitter and receiver chassis out of sight. A JLINK port is also included on the receiver for direct connection with JLINK compatible JL Audio products.
Especially useful in system designs that include remote source applications, lengthy signal cable runs or demanding installations due to challenging architecture, the JLINK TRX system gives you the freedom to position a source unit or outlying amplifier/powered loudspeakers (subwoofer or full-range) almost anywhere you would like.
Features
Outstanding fidelity in subwoofer and full-range applications
Bit-Perfect Digital PCM Stereo Wireless Technology (16 bit / 48 kHz)
RCA-type input/output connectors are compatible with most audio equipment
Up to 3 JLINK transmitters can be used concurrently (3 channels to choose from)
Up to 4 JLINK receivers (sold separately) can be paired to each JLINK transmitter
Receiver includes JLINK port for use with compatible JL Audio products.
Specifications
System Specifications
S/N Ratio: 80 dB @ 1 kHz, 500 mV
THD+N: 0.02% @ 1 kHz, 500 mV
Crosstalk: >75 dB @ 1 kHz, 500 mV
Frequency Response: 16 Hz – 22 kHz (+0, -1dB)
Wireless Range: 100 feet / 30 meters (typical)
Wireless Channels: 3 available, selectable via switch
Latency: 14 mS
AC Power Adaptor: 1 A, 5 volts DC
Transmitter Specifications
Input Impedance: 25 kΩ
Outputs: Bit-Perfect PCM Stereo Digital via 2.4 GHz Wireless
Receivers Supported: Up to 4
Bit Depth/Sample Rate: 16 Bit / 48 kHz
Power Requirements: 200 mA, 5 volts (via AC adaptor)
Inputs: Analog, left and right RCA-type
Receiver Specifications
Inputs: Bit-Perfect PCM Stereo Digital via 2.4 GHz Wireless
Inputs: Analog, left & right RCA-type Analog via JLINK port to compatible product
Output Impedance: 250 Ω
Full Scale Output Voltage: 1.2 V
Power Requirements: 100 mA, 5 volts (via AC adaptor or JLINK port)
Approximate Dimensions
Transmitter
Height: 1.12 in
Width: 3.5 in
Depth: 3.5 in
Receiver
Height: 1.12 in
Width: 3.5 in
Depth: 3.5 in
Read More
California customers
Proposition 65 WARNING
WARNING: Cancer and Reproductive Harm

Specifications
General
Color
Black
Accessory Type
Wireless Audio Transmitter/Receiver
Brand Compatibility
Universal
In the Box
1 x Receiver, 1 x Transmitter,
Operating Temperature
32°F to 104°F (0°C to 40°C)
Warranty Information
Parts Warranty
3 Years Limited
Labor Warranty
3 Years Limited
Approximate Weight
Package Weight (lbs)
2
Approximate Dimensions
Package Size HxWxL (in)
6 x 5 x 6
